E3SB25E001803E,无源晶体谐振器,3225贴片晶振,物料编码E3SB25E001803E,型号E3SB系列晶振,频率为25MHz,精度为±20ppm,负载电容12PF,工作温度范围:-40℃~85℃,尺寸为3.2*2.5mm,无源晶体谐振器,石英晶体谐振器,贴片晶振,台产进口晶振,晶振厂家,无源晶振,3225贴片晶振,3225石英谐振荡,石英晶振适用于数码相机,数码游戏机,数码玩具,数码电视,数码手机等产品。
E3SB25E001803E,无源晶体谐振器,3225贴片晶振
参数表 | |
型号 | E3SB |
频率 | 25MHz |
负载电容 | 12PF |
精度 | ±20ppm |
工作温度范围 | -40℃-85℃ |
尺寸 | 3.2*2.5mm |
E3SB25E001803E,无源晶体谐振器,3225贴片晶振
物料编码 | 描述 | 型号 | 频率 | 精度 | 负载 | 工作温度范围 |
E3SB16E000028E | XTAL 3225 16MHZ, 10PF | E3SB | 16 MHz | ±10ppm | 10pF | -20°C ~ 75°C |
E3SB40E00090DE | XTAL 3225 40MHZ, 12PF/10/20/-30+ | E3SB | 40 MHz | ±20ppm | 12pF | -30°C ~ 105°C |
E3SB38E0X0006E | XTAL 3225 38.4MHZ, 10PF/10/10/-3 | E3SB | 38.4 MHz | ±10ppm | 10pF | -30°C ~ 85°C |
E3SB40E00010KECBB8 | XTAL 3225 40MHZ, 6PF/7/15/-40+10 | E3SB | 40 MHz | ±15ppm | 6pF | -40°C ~ 100°C |
E3SB39E000006E | XTAL 3225 39MHZ, 10PF | E3SB | 39 MHz | ±15ppm | 10pF | -40°C ~ 100°C |
E3SB38E0X1806E | XTAL 3225 38.400MHZ, 10PF | E3SB | 38.4 MHz | ±20ppm | 10pF | -40°C ~ 85°C |
E3SB48E000801ECBB8 | XTAL 3225 48MHZ, 12PF/10/10/0+85 | E3SB | 48 MHz | ±10ppm | 12pF | 0°C ~ 85°C |
E3SB12E00004EE | XTAL 3225 12MHZ, 12PF | E3SB | 12 MHz | ±35ppm | 12pF | -40°C ~ 120°C |
ETSB37E0X0014E | XTAL 1612 37.4MHZ,16PF | ETSB | 37.4 MHz | ±10ppm | 16pF | -30°C ~ 85°C |
ETSB38E0X0005E | XTAL 1612 38.4MHZ, 10PF/10/10/-3 | ETSB | 38.4 MHz | ±10ppm | 10pF | -30°C ~ 85°C |
ETSB24E000003E | XTAL 1612 24MHZ, 8PF | ETSB | 24 MHz | ±10ppm | 8pF | -30°C ~ 85°C |
ETSB48E007500ECBB8 | CRYSTAL 48.0000MHZ 10PF SMD | ETSB | 48 MHz | ±15ppm | 10pF | -20°C ~ 70°C |
ETSB48E007502E | XTAL 1612 48MHZ, 10PF/10/15/-40+ | ETSB | 48 MHz | ±15ppm | 10pF | -40°C ~ 85°C |
ETSB32E000003E | XTAL 1612 32MHZ, 8PF | ETSB | 32 MHz | ±10ppm | 8pF | -30°C ~ 85°C |
ETSB60E003700E | XTAL 1612 60MHZ,9P | ETSB | 60 MHz | ±20ppm | 9pF | -30°C ~ 105°C |
E3SB14E0X0002E | XTAL 3225 14.7456MHZ, 12PF | E3SB | 14.7456 MHz | ±30ppm | 12pF | -40°C ~ 85°C |
E3SB10E000007E | XTAL 3225 10MHZ, 12PF | E3SB | 10 MHz | ±30ppm | 12pF | -40°C ~ 85°C |
E3SB25E00000DE | XTAL 3225 25MHZ, 10PF | E3SB | 25 MHz | ±10ppm | 10pF | -20°C ~ 70°C |
E3SB48E00000TE | XTAL 3225 48MHZ, 18PF | E3SB | 48 MHz | ±30ppm | 18pF | -20°C ~ 70°C |
E3SB50E00002AE | XTAL 3225 50MHZ, 9PF | E3SB | 50 MHz | ±18ppm | 9pF | -40°C ~ 105°C |
ETSB27E0X0003E | XTAL 1612 27.12MHZ, 10PF | ETSB | 27.12 MHz | ±10ppm | 10pF | -30°C ~ 85°C |
ETSB25E004800E | XTAL 1612 25MHZ,8P | ETSB | 25 MHz | ±15ppm | 8pF | -40°C ~ 85°C |
ETST00327000JE | XTAL 3215 32.768KHZ 12.5P | ETST | 32.768 kHz | - | 12.5pF | -40°C ~ 85°C |
