X5HGGJNINF-100.000000,高频晶振,台产泰艺晶振

频率为100MHz,尺寸为8.0*3.1mm

X5HGGJNINF-100.000000,高频晶振,台产泰艺晶振，物料编码为X5HGGJNINF-100.000000，型号为X5系列晶振，频率为100MHz，精度为±5ppm，负载电容为20pF，工作温度为-55℃~125℃，尺寸为8.0*3.1mm，插件晶振，石英晶体，高频晶振，台产泰艺晶振，广泛应用于mp5，mp4，无线电源，智能录音笔等产品。

订购热线：0755-27839151

1XQJX

2GGCS

TY-2

X5HGGJNINF-100.000000,高频晶振,台产泰艺晶振

参数表
型号	X5
频率	100MHz
精度	±5ppm
负载电容	20pF
工作温度	-55℃-125℃
尺寸	8.0*3.1mm

3CC

TY-3

X5HGGJNINF-100.000000,高频晶振,台产泰艺晶振

X5尺寸图

原厂编码	参数描述	型号	频率	频率稳定度	频率容差	负载电容	工作温度
X5HGGJNINF-100.000000	CRYSTAL 100.0000MHZ 20PF THOLE	X5	100 MHz	-	±5ppm	20pF	-55°C ~ 125°C
XSCEECNANF-8.000000	CRYSTAL 8.0000MHZ 10PF SMD	XS	冠杰电子	±30ppm	±30ppm	10pF	-20°C ~ 70°C
XSCEGCNANF-10.000000	CRYSTAL 10.0000MHZ 10PF SMD	XS	10 MHz	±50ppm	±30ppm	10pF	-20°C ~ 70°C
XSCGGCNANF-24.576000	CRYSTAL 24.5760MHZ 10PF SMD	XS	24.576 MHz	±50ppm	±50ppm	10pF	-20°C ~ 70°C
XSDEECNANF-25.000000	CRYSTAL 25.0000MHZ 12PF SMD	XS	25 MHz	±30ppm	±30ppm	12pF	-20°C ~ 70°C
XSDEELNANF-12.000000	CRYSTAL 12.0000MHZ 12PF SMD	XS	12 MHz	±30ppm	±30ppm	12pF	-40°C ~ 85°C
XSDEELNANF-13.560000	CRYSTAL 13.5600MHZ 12PF SMD	XS	13.56 MHz	±30ppm	±30ppm	12pF	-40°C ~ 85°C
XSDEELNANF-25.000000	CRYSTAL 25.0000MHZ 12PF SMD	XS	25 MHz	±30ppm	±30ppm	12pF	-40°C ~ 85°C
XSDEGCNANF-16.000000	CRYSTAL 16.0000MHZ 12PF SMD	XS	16 MHz	±50ppm	±30ppm	12pF	-20°C ~ 70°C
XSFGGLNANF-20.000000	CRYSTAL 20.0000MHZ 16PF SMD	XS	20 MHz	±50ppm	±50ppm	16pF	-40°C ~ 85°C
XSGEECNANF-16.000000	CRYSTAL 16.0000MHZ 18PF SMD	XS	16 MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
XSGEELNANF-25.000000	CRYSTAL 25.0000MHZ 18PF SMD	XS	25 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
XSGEGLNANF-13.000000	CRYSTAL 13.0000MHZ 18PF SMD	XS	13 MHz	±50ppm	±30ppm	18pF	-40°C ~ 85°C
XSHEECNANF-25.000000	CRYSTAL 25.0000MHZ 20PF SMD	XS	25 MHz	±30ppm	±30ppm	20pF	-20°C ~ 70°C
XSHEELNANF-25.000000	CRYSTAL 25.0000MHZ 20PF SMD	XS	25 MHz	±30ppm	±30ppm	20pF	-40°C ~ 85°C
XSHGGLNANF-11.059200	CRYSTAL 11.0592MHZ 20PF SMD	XS	11.0592 MHz	±50ppm	±50ppm	20pF	-40°C ~ 85°C
XSHGGLNANF-12.000000	CRYSTAL 12.0000MHZ 20PF SMD	XS	12 MHz	±50ppm	±50ppm	20pF	-40°C ~ 85°C
XSHGGLNANF-16.000000	CRYSTAL 16.0000MHZ 20PF SMD	XS	16 MHz	±50ppm	±50ppm	20pF	-40°C ~ 85°C
XSHGGLNANF-24.000000	CRYSTAL 24.0000MHZ 20PF SMD	XS	24 MHz	±50ppm	±50ppm	20pF	-40°C ~ 85°C
XSDEELAANF-12.000000	CRYSTAL 12.0000MHZ 12PF SMD	XS	12 MHz	±30ppm	±30ppm	12pF	-40°C ~ 85°C
XSDEELAANF-13.560000	CRYSTAL 13.5600MHZ 12PF SMD	XS	13.56 MHz	±30ppm	±30ppm	12pF	-40°C ~ 85°C
XSGEECAANF-16.000000	CRYSTAL 16.0000MHZ 18PF SMD	XS	16 MHz	±30ppm	±30ppm	18pF	-20°C ~ 70°C
XSGEELAANF-25.000000	CRYSTAL 25.0000MHZ 18PF SMD	XS	25 MHz	±30ppm	±30ppm	18pF	-40°C ~ 85°C
XSHEECAANF-25.000000	CRYSTAL 25.0000MHZ 20PF SMD	XS	25 MHz	±30ppm	±30ppm	20pF	-20°C ~ 70°C
XSHEELAANF-25.000000	CRYSTAL 25.0000MHZ 20PF SMD	XS	25 MHz	±30ppm	±30ppm	20pF	-40°C ~ 85°C
XSGCCLNANF-25.000000	CRYSTAL 25.0000MHZ 18PF SMD	XS	25 MHz	±20ppm	±20ppm	18pF	-40°C ~ 85°C
XSGCECNANF-8.000000	CRYSTAL 8.0000MHZ 18PF SMD	XS	8 MHz	±30ppm	±20ppm	18pF	-20°C ~ 70°C
